Spider lift
RE22-22HY
STANDARD EQUIPMENT
- Articulated with double telescopicbooms
- 360° continuous turret rotation
- ±80° platform rotation
- CAN-bus controlled
- One-button outrigger leveling
- Variable outrigger system
- Radio remote control
- Go home function
- Track width adjusting system
- White non-marking rubber tracks
- Full proportional control system
- Auto leveling platform
- Emergency hand pump
- Hour meter
- Hydraulic safety devices
- Platform overload sensor
- Removable aluminium platform
- Real-time data display in the control panel
- Double speed drive
- AC220V electric motor
- Standard painting: RAL5021
- AC220V electric socket in the platform
- Storage box for the radio
- Diesel engine
ACCESSORIES
- 4 sliding pads
- Proportional valve emergency lever
- AC220V power cable for electric motor
- 10m control cable for radio
- 2 batteries for radio
OPTIONS
- Special painting
- 51.2-280AH Lithium-ion battery pack
- Lithium battery + diesel engine (hybrid)
- Lifting device (260kg capacity)
- Anti-collision kit for the platform
TECHNICAL PARAMETERS
PERFORMANCE
- Model
- Platform capacity
- Gradeability (max.)
- Travel speed (max.)
- Platform rotatable
- Turntable rotation Live
- load in travelling position
- Live load in working
- position Control
- ES220
- 230 kg
- 30%
- 1.3 km/h
- ±80°
- 360° (continuous) 4.35
- kN/m2
- kN/m2
- Radio remote control
POWER SOURCES
- Model
- Combustion engine (diesel)
- Electric motor Lithium
- battery (pure electric)
- Lithium battery (hybrid)
- ES220
- Kubota D902 15.9kw
- AC220V / 3kw
- 51.2V-280AH (option)
- 25.6V-230AH (option)
TECHNICAL DATA
- Model
- Working height
- Platform height
- Horizontal outreach
- Up and over clearance
- Negative working capacity
- Track width-adjustable
- Total weight
- A Platform (length)
- B Platform (width)
- C Platform (height)
- D Stowed length
- E Stowed length (without platform)
- F Stowed width
- G Stowed width (without platform)
- H Stowed height (min.)
- I Length-outrigger footprint
- J Width-outrigger footprint
- K Track (length*width)
- Standard painting
- ES220
- 21.8 m
- 19.8 m
- 8.6 m
- 13.8 m
- -2 m
- 900 mm / 1150 mm
- 3250 kg
- 1.5 m
- 0.7 m
- 1.1 m
- 4975 mm
- 4530 mm
- 1500 mm
- 900 mm
- 1980 mm
- 3690 mm / 4910 mm
- 2560 mm / 3745 mm
- 1425 mm × 230 mm
- RAL 5021
